THE SB COMPACT IS A RUGGED SOLUTION FOR NARROW LANES WITH MANY COMBINATION POSSIBILITIES.

Light implement frames with hydraulic width adjustment for under-vine cultivation for tractor mounting in front or rear. A pump tank hydraulic unit is available for smaller tractors. Ideal for mounting the modern under-vine weeding system RADIUS SL or ROTARY BRUSH. SB1 AND SB2 are available in two different widths for SB MONO the one hand sided solution for different row width with hydraulic width adjustment of 20 inches.

Advantages:

  • Hydraulic width adjustment
  • Front or rear mounted available

TALK TO A SALESPERSON

This field is required
This field is required
This field is required Not a valid number!
This field is required This is not a valid email.
reCAPTCHA is required

For more information on how we collect, hold, use and disclose personal information, please see our privacy policy.

Model Specifications


  SB COMPACT
Weight: 135 kg
Base frame width: 740 - 1.280 mm
Width adjustment: 500 mm

Row width with Radius SL 370: 1.480 - 2.020 mm
Row width with Radius SL 500: 1.740 - 2.280 mm
Row width with Radius SL 620: 1.980 - 2.520 mm
